ResinLab EP1112 Epoxy Encapsulant Part A Black 5 gal Pail

Part number: EP1112 BLACK - A PL Manufacturer SKU: EP1112 BLACK A PL
ResinLab EP1112 Epoxy Encapsulant Part A Black 5 gal Pail
Quantity Price
1 $721.37 721.370000000 USD New Limited Availability EP1112 BLACK - A PL
2 $669.84 669.840000000 USD New Limited Availability EP1112 BLACK - A PL
3+ $627.69 627.690000000 USD New Limited Availability EP1112 BLACK - A PL
Usually Ships in 2-3 Business Days. NON-RETURNABLE.
  • A Made in the USA
  • K Haz Class 9

ResinLab EP1112 Black is a two component, room temperature curing, unfilled epoxy encapsulant that is used for small to medium sized castings and penetrating circuitry. It is electronic grade, low viscosity, flexible, good wicking, gives good air release, and has excellent thermal shock and cycling properties. It is resistant to most organic solvents and water. Part A, 5 gal Pail.

<p>ResinLab EP1112 Black is a two component, room temperature curing, unfilled epoxy encapsulant that is used for small to medium sized castings and penetrating circuitry. It is electronic grade, low viscosity, flexible, good wicking, gives good air release, and has excellent thermal shock and cycling properties. It is resistant to most organic solvents and water. Part A, 5 gal Pail.</p>
Typical Use: Its low viscosity allows for good wicking and penetration into components and circuitry and also gives good air release.
Chemical Composition: Epoxy
Color: Black
Components: 2 part
Cure System: Room Temperature
Cure Time: 6 to 12h @ room temperature
Dielectric Strength: 410 V/mil
Elongation: 50% @ break
Flash Point: >154 °C
Hardness: 70 D
Mix Ratio: 1:1 by volume; 100:85 by weight
Service Temperature: -40 to 150 °C
Specific Gravity: Part A: 1.11; Mixed: 1.04
Tensile Strength: 1,200 psi
Thermal Conductivity: 0.17 W/mK
Viscosity: Part A: 1,200; Mixed: 1,200
Volume Resistivity: 4 x 10^14 ohm-cm
Working Time: 10 to 15min
